Shear Beam Load Cell

8500 INR/Piece

Get a Price/Quote

Product Details:

Usage Tank & Vessel Weighing
Product Type Shear Beam Load Cell
Condition New
Voltage 5-15 Volt (v)
Length of Belt 1-20 Meter (m)
Feature Hermetically sealed
Attributes Strong Durable
Click to View more
Share Your Product:

Request to Call Back Send Inquiry

Shear Beam Load Cell Price And Quantity

Minimum Order Quantity 1 Piece
Price 8500 INR/Piece

Shear Beam Load Cell Product Specifications

Length of Belt 1-20 Meter (m)
Voltage 5-15 Volt (v)
Product Type Shear Beam Load Cell
Usage Tank & Vessel Weighing
Condition New
Attributes Strong Durable
Feature Hermetically sealed

Shear Beam Load Cell Trade Information

Payment Terms Cash Advance (CA)
Delivery Time 1-7 Days
Main Domestic Market All India

Product Description

Shear Beam Load Cell is widely acclaimed among our customers owing to its premium quality and performance. This product is widely used in where operators need to measure compressive forces. The offered load cell is capable of withstanding heavy loads, impacts, and shear forces. It has got the capability of enduring heavy loads, heat, and shear forces, therefore, it does not degrade in quality or become inferior in the long run. Shear Beam Load Cell can be effortlessly integrated with the system by following simple installation guidelines.

Specification

Application	Tank & Vessel Weighing
Cable Length	1-20 metre
Capacity	22.5 Kg
Combined Error	<+/-0.03max
Compensated Temperature Range	-10 to +40 Deg C
Creep Error (30 minutes)	<+/-0.030
Features	Hermetically sealed
Ingress Protection	IP68
Insulation resistance at 50V DC	>= 1000 M Ohm
Material	Stainless Steel
Maximum Safe Overload	150% FS
Operating Temperatue Range	-20 to +70 Deg C
Recommended Excitation Voltage	5 to 15V DC
Temperature Effect on Output	+/-0.001
Temperature Effect on Zero	+/-0.002
Type	Single Ended Shear Beam
Ultimate Safe Overload	300% FS
Zero balance	+/- 1% FS
